Cable U/utp Systimax Cat6a Gigaspeed X10d(R) 1091b Etl X305mts

SOMOS TODOCONECTORES
CABLE U/UTP SIN BLINDAJE SYSTIMAX® CAT-6A 760107078 | 1091B SLT C6A 4/23 U/UTP W1000
SKU 4384
Modelo 760107078
Marca SYSTIMAX®
Cantidad publicada 1 rollo de 305 mts

Características
ANSI/TIA Category 6A
Diameter Over Insulated Conductor 0.864 mm | 0.034 in
Diameter Over Jacket, nominal 7.239 mm | 0.285 in
Jacket Thickness 1.295 mm | 0.051 in
Conductor Gauge, singles 23 AWG
Cross Section Drawing 760107078 | 1091B SLT C6A 4/23 U/UTP W1000
Characteristic Impedance 100 ohm
Characteristic Impedance Tolerance ±15 ohm
dc Resistance Unbalance, maximum 4 %
dc Resistance, maximum 7.61 ohms/100 m | 2.32 ohms/100 ft
Dielectric Strength, minimum 1500 Vac | 2500 Vdc
LP (Limited Power) Rating 0.5 A
Mutual Capacitance at Frequency 6.0 nF/100 m @ 1 kHz
Nominal Velocity of Propagation (NVP) 65 %
Operating Frequency, maximum 550 MHz
Operating Voltage, maximum 80 V
Remote Powering Fully complies with the recommendations set forth by IEEE 802.3bt (Type 4) for the
safe delivery of power over LAN cable when installed according to ISO/IEC 14763-2,
CENELEC EN 50174-1, CENELEC EN 50174-2 or TIA TSB-184-A
Conductor Material Bare copper
Insulation Material Polyolefin
Jacket Material PVC
Polyolefin
